240 PLUS

Blister Packing Machine Model.

Innojet's Lab & Pilot Granulation Equipment: Leading the Way

Control of the four critical variables during the granulation: mixing speed / binding liquid flow

Three interchangeable bowls of 2, 5 and 10 litres.

Equipped with Siemens PLC and touch panel. This allows to optimise the process and apply relevant parameters.

DESCRIPTION	Model: 240 Plus
PVC Base Film Width	210 mm Max.
PVC Base Film Thickness	0.25 - 0.4 mm Max.
Sealing Foil Width	206 mm Max.
Sealing Foil Thickness	0.02 - 0.04 mm Max.
Format Area	210 mm X 100 mm
Forming Depth	16 mm
Max. Output	Round Shape 240 packs/min & Oval Shape 140 packs/min
Machine Dimensions in mm.	L: 3100 \| W: 1100 \| H: 2000
Machine Weight	1150 kg. (Approx)

Base Material: PVC/PVC-PVDC/ACCLAR/TRIPLEX/PP

Lidding Material: Aluminum with Heat Sealable Lacquer Coating.

Compressed Air: 7 CFM dry air at pressure 6.0 kgs / cm ²

Water Cooler: 150 Liters / Hour Temperature 15°C to 20°C @pressure 2.5 kg/cm ².

Electrical Power: 7.5 KW, 415 V, 50 hz, 3 Phase + N+E.

Earthing Cable: Copper, 2.5 mm ² (Minimum).
